DetailµSIRIUS Focused
Next generation UV source with high intensity and small spot size down to 300 µm.
The µSIRIUS is a new generation of duo-plasmatron based discharge light sources. Its body fully constructed by additive manufacturing increases the stability and performance compared to the existing UV light sources. The imprinted water cooling reduces the dimensions of the source and allows us to impoove the anode geometry. The photon poutput can be increased by on order of magnitude compared to the existing solutions. A new type of filament comes with a significatnly increased life time of > 5000 hours.
The ETC capillary focussing capillary. Due to the duo-plasmatron principle, the UV source generates a tiny emission spot, which can be focussed on the surface without any artificial apertures. The new capiallry design reduces the spot size down to 300 µm with no loss in the photon flux.
SPECIFICATIONS
| Photon Flux Density | > 1x1014 photons/(s*mm²) |
| Spot Size | < 300 µm |
| Capillary | ETC |
| Operating Gases | All Noble Gases |
| Working Pressure | < 5x10-8 mbar |
| Working Distance | 15 mm |
| Working Principle | Duo Plasmatron |
| Monochromator | Available |
| Mounting Flange | DN35CF |
