PHOIBOS 225 1D-DLD

High Peformance Hemipsherical Energy Analyzer with 1D-DLD detector for UPS, XPS, ISS and LEISS.

The PHOIBOS 225 hemispherical energy analyzer is a powerful tool for modern photoelectron spectroscopy. This analyzer can be operated in all relevant analysis modes, such as XPS, UPS, as well as AES, ISS and LEISS. Its design and the modular supplementary hardware makes this analyzer the most versatile PES analyzer in the market. It can easily be upgraded with all available SPECS detection systems.

The integrated 1D-DLD detector is the best performing detection system available. The direct detection of electron signals yield quantitative counts per second (cps). The powerful electronics can aquire ultrafast snapshot measurements of the energy spectrum with up to 1200 energy channels as well as continous sweeping energy spectra. Its low dark count rate and high linearity make this detector outstanding for XPS analyis.

The energy analyzer section is equipped with 8 customizable entrance and 3 exit slits for UPS and XPS. The analyzer comes with a highly stable power supply, the HSA 3500 plus, for best performance in a wide kinetic energy range up to 3500 eV kinetic energy.

KEY FEATURES

225 mm Mean Radius
Quantitative Analysis
High Count Rate and Linearity
Low Noise and Dark Count Rate
65 mm Detector Area
Fast Snapshot Measurements

MADE FOR THESE METHODS
SPECIFICATIONS
SPARE PARTS
DOWNLOADS

MADE FOR THESE METHODS

3

XPS, Chemical Mapping

X-ray photoelectron spectroscopy (XPS) is a widely used method for chemical analysis. By surface imaging or mapping a chemical map can be recorded

AES, SAM, SEM

Auger electron spectroscopy/microscopy detects the energy distribution of secondary electrons returning from a surface locally for chemical analysis.

ARPES

Angle-Resolved Photoelectron Spectroscopy detects the energy and angle distribution of photoelectrons to determine the electronic structure of solids.

SPECIFICATIONS

PHOIBOS 225 1D-DLD

Operation

Energy Dispersion by	Hemisphere
Slits/Apertures	8 Entrance, 3 Exit slits and Iris aperture
Lens Modes	Angular resolved Mode Transmission Mode Spatially resolved Mode Angular resolved
Acceptance Angle	±15°
Kinetic Energy Range	0 - 3500 eV
Pass Energies	0 - 550 eV continously adjustable
Detector	1D-DLD Detector
Detector Channels	Max. 960 energy channels (240 and 120 channels for binning 4 and 8, respectively)
Measurement Modes	Snapshot Mode Sweeping Mode Fixed Mode
Energy Window	14% of Pass Energy
Electronics	HSA 3500 plus HT 100
Working Pressure	10^-11 to 10^-7 mbar
