DetailPHOIBOS 150 EP 2D-DLD
State of the art hemispherical energy analyzer with 2D-DLD detector for photoelectron spectroscopy measurements (XPS and UPS) in the pressure regime from UHV to elevated pressure regime (EP) up to 1 mbar.
The PHOIBOS 150 EP analyzer is an integral part of all PHOIBOS 150 NAP analysers, but in contrast to the NAP version is operating without the wide acceptance angle pre-lens. Therefore, it has 3 diferential pumping stages and can operate at pressures up to 1 mbar. The first differential pumping stage is separated from the analysis chamber by a nozzle with a customizable opening at the tip with diameters between 0.3 mm and 5 mm.
Depending on its configuration the PHOIBOS 150 EP can perform XPS und UPS measurements at pressures of up to 1 mbar. It offers full flexibility to be equipped with all available 1D and 2D detectors. The modular building concept enables the user to upgrade a PHOIBOS 150 EP to a full PHOIBOS 150 NAP analyzer by simply adding the pre-lens together with the corresponding electronics and additional differential pumping.
KEY FEATURES
- Elevated working pressures up to 1 mbar depending on configuration
- Upgradeable to complete PHOIBOS 150 NAP analyser including wide acceptance angle pre-lens
- Up to 30° acceptance angle in angle in resolved and transmission mode
- High energy and angular resolution
- Working range up to 3.5 keV
- Large pass energy range
- 3 differential pumping stages
- Fast detectors with high dynamic range for fast real time data acquisition in snapshot mode
- Full detector flexibility (MCD, 1D-DLD, 2D-DLD, 2D-CCD/-CMOS)
SPECIFICATIONS
| Energy Dispersion | Hemisphere |
| Slits/Apertures | 8 Entrance, 3 Exit slits and Iris aperture |
| Magnetic Shielding | Double µ-Metal Shielding |
| Lens Modes | Angular Resolving, Transmission and Magnification (Lateral Resolved) Lens Modes |
| Kinetic Energy Range | 0 - 3500 eV |
| Pass Energies | 0 - 550 eV continously adjustable |
| Detector | 1D-DLD |
| Measurement Modes | Snapshot mode, Sweeping mode, Fixed energy mode |
| Energy Window | 13% of Pass Energy |
| Electric Isolation | up to 3.5 keV |
| Electronics | HSA 3500 plus HT102 |
| Working Pressure | up to 1 mbar (up to 10-4 mbar without nozzle) |
| Mounting Flange | DN150 CF (8" OD) |
| Working Distance | 300 - 500 µm (for standard nozzle with 300 µm diameter) |
| Acceptance Angle | ±15° |
| Angular Resolution | < 0.1° |
| Energy Resolution | < 3 meV |
| Lateral Resolution | < 100 µm |
| Smallest Acceptance Spot | 100 µm |
| XPS Count Rates UHV | 20 kcps* |
| XPS Count Rates 1 mbar | 16 kcps* |
| Detector Channels | 800 x 640 (with channel binning) |
| . | * Ag 3d, FWHM < 0.85 eV, non-monochromatic X-ray source XR 50, Mg Kα anode, 300 W, N2 gas atmosphere |
SPARE PARTS
Spare channelplate set for 1D & 2D-DLD 100 & 2D-DLD 150. Not suitable for 1D-DLD 150
Spare electrical feedthrough for all DLD detectors. Connection flange for the ACU unit
PHOIBOS 150 analyzer main flange gasket for Releases R5, R6, R7
Replacement feedthrough for PHOIBOS Release R5 & R6 iris mechanism
Replacement spindle for PHOIBOS Release R5 & R6 iris mechanism
Replacement iris mechanism for PHOIBOS Release R5 & R6
