DetailUVS 10/35
The UVS 10/35 is a simple and easy to use UV light source with long time proven design.
The SPECS UVS 10/35 is an easy to use and robust UV source. It provides an excellent He I to He II ratio and can be operated with many different gases. The souurce is designed for longest operation time with extreme stability and easy ignition.
The UV source fits literaly every system on any free DN40CF flange, while the sample to flange distance is not critical. An optional polarizer is available to polarize the normally unpolarized light.
SPECIFICATIONS
| Operating Gases | He, Ne, Ar, Kr, Xe |
| Working Pressure | < 5x10-7 mbar |
| Working Distance | 15 mm |
| Working Principle | High Voltage Discharge |
| Photon Flux | > 8x1015 photons/(s*Sr) (Source Only) |
| Spot Size | < 2 mm |
| Capillary | Quartz (0.8 or 1.3 mm) |
| Mounting Flange | DN35CF |
SPARE PARTS
Replacement membrane for VAT leak valve
Replacement Piezo actor for SPECS Piezo Gas Inlet system
New VAT leak valve
Replacment gasket to fix the capillary of SPECS UVS 10/35
Replacement anode flange for SPECS UVS 10/35
Replacement discharge capillary for SPECS UVS 10/35
Replacement Fan for SPECS UVS 10 /35
Replacement heat sink part for SPECS UVS 10/35 for the ceramic insulator
Replacement lock ring for SPECS UVS 10/35 source to fix the capillary assembly
Quartz capillary for SPECS UVS 10/35 source with inner diameter of 0.8 mm. Length 200 mm. Customized length available on request.
Quartz capillary for SPECS UVS 10/35 source with inner diameter of 1.3 mm. Length 200 mm. Customized length available on request.
Quartz capillary for SPECS UVS 10/35 source with inner diameter of 1.3 mm. Length 300 mm. Customized length available on request.
Tool for easy capillary exchange for SPECS UVS 10/35 Rel. 2
