PHOIBOS 150 with 2D-CMOS and 3D(2D) Spin Mott Detector

Hemispherical Energy Analyzer with 2D CMOS Detector for XPS, ARPES, ISS and LEISS and MOTT Detector for Spin Measurements with 150 mm Mean Radius

Spin detector for Hemispherical Energy Analyzer PHOIBOS 225 Mott MCD

The PHOIBOS 150 hemispherical energy analyzer is the-state-of-the-art analysis solution for photoelectron spectroscopy. This analyzer can be operated in all relevant analysis modes, such as ARPES, XPS, UPS, as well as AES, ISS and LEISS. Its design and the modular supplementary hardware makes this analyzer the most versatile PES analyzer in the market.

The patented design of the detector section allows measurements of all three spin components and subsequent 2D ARPES merasurements. The 2D detector is a full scale 2D CMOS detector un undiminished performance in standard PES. The spin channel consist of a 90° deflector to acess the out of plan spin component and a special rotator lens to swich between the two in plance components of the spin.

The actual spin detector is based on the Rice University mini MOTT scheme, where a thin tungesten target on high voltage (25 kV) is used as a spin selective scattering target. With the MOTT detector it is possible to measure 4 channels in one experminet (two spin components with spin up/down, respectively).

The energy analyzer sectionis equipped with 8 customizable entrance and 3 exit slits. For highest energy resolution the entrance slit can be chosen down to 50 µm, providing achievable energy resolution better than 1.8 meV. The analyzer comes with a highly stable power supply, the HSA 3500 plus, for best performance in a wide kinetic energy range.

A classical CCD camera detection system is available on request.

KEY FEATURES

  • Robust Spin Detector with long lifetime
  • High Energy Scattering Scheme
  • Full Scale 2D Detector
  • Spin Rotator and 90° Deflector
  • High Energy and Angular Resolution
  • 150 mm Mean Radius

MADE FOR THESE METHODS

2

SPECIFICATIONS

PHOIBOS 150 with 2D-CMOS and 3D(2D) Spin Mott Detector
Operation
Kinetic Energy Range

0-3500 eV in PES
0-1500 in Spin PES

Pass Energies

0-550 eV Continously Adjustable
0-200 eV in Spin Detector Channel

Energy Dispersion

Hemisphere

Lens Modes

Transmission Mode, Angular Resolved Mode, Magnification (Lateral Resolved) Mode

Measurement Modes

Snapshot Mode, Sweeping Mode, Fixed Energy Mode

Detector

2D CMOS Detector
3D Spin Mott Detector

Slits/Apertures

8 entrance and 3 exit slits and iris aperture

Energy Window

13% of Pass Energy

Electronics

HSA 3500 +

Working Pressure

10-11 to 10-7 mbar

Performance
Energy Resolution

< 1.8 meV in ARPES Mode
< 10 meV in Spin Mode

Angular Resolution

< 0.1° in ARPES Mode
<0.15° in Spin Mode

k-Resolution

N/A

Acceptance Angle

±15°, ±7°, ±4° and ±3° in ARPES Mode

Lateral Resolution

< 35 µm

Smallest Acceptance Spot

100 µm

XPS Count Rates UHV

tba

Detector Channels

1285 x 730 (with Channel Binning)

Sherman Function /FoM

Sherman Function: 0.16
FoM=0,00015

Mounting
Working Distance

40 mm

Mounting Flange

DN100CF (6" OD)

Magnetic Shielding

Double µ-Metal Shielding

Electric Isolation

> 10 keV

APPLICATION NOTES

SPARE PARTS

8
Product image
Product description
Article No.

Channelplates Set - 1 pair MCP 40

Spare channelplate set for all 40 mm CCD detectors

2060009045
Phosphor screen

Spare phosphor screen for all 40 mm CCD detectors. Exchange with channelplates is recommended.

2060008804
Cu gasket for PHOIBOS 150

PHOIBOS 150 analyzer main flange gasket for Releases R5, R6, R7

2074050088
Rotary feedthrough for IRIS

Replacement feedthrough for PHOIBOS Release R5 & R6 iris mechanism

2060001175
Spindle with Spur and Bevel Gear for Iris

Replacement spindle for PHOIBOS Release R5 & R6 iris mechanism

2055021656
Tubus 3 with Iris

Replacement iris mechanism for PHOIBOS Release R5 & R6

2079150291
Channeltron for Spin-detector

Single replacement channeltron for SPECS MOTT spin detector

2079170042
Channeltron-Arrayset (6)

Replacement channeltron set for SPECS MOTT spin detector

2100004833
