SC5 add-on

With growing set-up complexity, or when multiple stages need to be controlled, 8 input and output channels might simply not be enough. One additional SC5 instantaneously doubles that number to 16. For even more complex experiments, a maximum of 3 SC5s can be connected to the Nanonis SPM Control System base package, transforming the instrument into a 24 outputs and 24 inputs system.

Nanonis SC5
Nanonis SC5

While increasing the number of channels with conventional systems means adapting the measurement software and potentially changing the workflow, the modularity of the Nanonis SPM Control System avoids all these drawbacks. The additional SC5 signals are seamlessly integrated into the Nanonis software allowing immediate productivity.

Additional SC5s can be combined with additional SO5s (16-output channels) if more outputs than inputs are required.

KEY FEATURES

  • 8 additional high precision and low noise 20-bit analog outputs (22-bit with hrDAC)
  • 8 additional low-noise 18-bit analog inputs
  • Up to a total of 24 I/O channels with two SC5 add-ons
  • Seamless integration of additional channels in the software

SC5 and SO5 add-on combinations supported by the BP5e

ConfigurationTotal number of outputsTotal number of inputs
BP5e88
1 SC5 add-on1616
1 SO5 add-on248
2 SC5 add-ons2424
1 SC5 and SO5 add-on3216
2 SO5 add-ons408
2 SC5 and 1SO5 add-on4024
1 SC5 and 2 SO5 add-on4816

MADE FOR THESE METHODS

1

SPECIFICATIONS

SC5 add-on
Performance
Analog inputs

If not otherwise specified, all specifications for ±10 V input range

Number of Connectors

8x BNC connector, differential

Differential input voltage range

± 10 V

Differential input voltage range

±10 V, ±1 V, ±100 mV, ±10 mV (with MCVA5)

Differential input impedance

2 MΩ

Input impedance

>10 TΩ to GND, >50 GΩ differential (with MCVA5)

Input bias current

<2 pA typ. (with MCVA5)

Analog bandwidth

DC – 100 kHz (-3 dB), 5th-order Butterworth low-pass filter

AD-converter

18-bit, no missing codes, 1 MS/s

Effective resolution

20-bit @ 60 kS/s, 22-bit @ 1 kS/s (oversampling)

INL

±2 LSB typical

DNL

±1 LSB typical

Input noise density

< 150 nV/√Hz @ 10 kHz, < 650 nV/√Hz @ 10 Hz

Input noise density

<4 nV/√Hz (<5.5 nV/√Hz) @10 kHz SE (differential)
< 5 nV/√Hz (<6 nV/√Hz) @ 10 Hz SE (differential)
<11 nV//√Hz (<15 nV/√Hz) @ 1 Hz SE (differential)
(With MCVA5 @ gain 100)

Input measurement noise

< 100 μVrms @ 1 MS/s, < 25 μVrms @ 60 kS/s, < 6.5 μVrms @ 240 S/s

Input noise 0.1 Hz - 10 Hz

<25 nVrms (< 32 nVrms) SE (differential)
(With MCVA5 @ gain 100)

12 h drift

< 80 μV (< 100 μV) @ 0 V (@ 9.9 V)

THD+N

> 120 dB @ 100 Hz, > 95 dB @ 1 kHz,
> 70 dB @ 10 kHz (9 V input signal)

CMRR

>125 dB @ 10 Hz >120 dB @ 100 Hz >100 dB @ 1 kHz (with MCVA5 @ gain 100)

Analog outputs

all specifications for ±10 V output range

Number of Connectors

8 x BNC connectors, referenced to AGND

Output voltage range

±10 V into 1 kΩ or larger
(0 to +10 V with internal jumper per channel)

Output impedance

<1 Ω, short circuit safe

Analog bandwidth

DC – 40 kHz (-3 dB),
5th – order Butterworth low-pass filter

DA-converter

20-bit, 1-ppm precision, 1 MS/s

Effective resolution

22-bit, patented hrDACTM technology with active glitch compensation

INL

< ±2 LSB max. < ±1 LSB typical

DNL

< ±1 LSB max. < 0.5 LSB typical

Output noise density

< 25 nV/√Hz @ 100 Hz, < 75 nV/√Hz @ 1 Hz

Output noise 0.1 Hz - 10 Hz

< 200 nVrms (0.1 – 10 Hz)

Output noise 10 Hz - 300 kHz

< 10 μVrms (10 Hz – 300 kHz)

12 h drift

< 1.5 μV (< 25 μV) @ 0 V (@ 9.9 V)

THD+N

> 93 dB @ 100 Hz, > 93 dB @ 1 kHz, > 79 dB @ 10 kHz (9V output signal)

Operation
Operating temperature

+5° C to +35° C

Power Supply

Built-in linearly regulated power supply, toroidal transformer, automatic line voltage detection. Max. 51 W

Power Input

100 – 240 V, 50 - 60 Hz

Electrical GND

10 kΩ AGND to chassis, decoupled from RC5e

Mounting
Dimensions

32.5 x 28 x 7 cm

Weight

4.2 kg
